From Design to Reality



The Future of Circuit Board  Manufacturing with FPM -Trinity




​01 | About


The world's first 3D printer that both prints boards and places components

FPM-Trinity is revolutionizing circuit board manufacturing. Using 3D printing technology, we create complete
circuit boards with mounted components from scratch.
This will change the way electronics are integrated into devices, adding value through new approaches to electronics design and manufacturing.

02 | Technology


Resin substate printing

The resin is highly heat resistant and
printed by an inkjet system.

Component placing

Components are placed by the integrated Fuji SMT machine.

Circuit printing

The circuit is formed with silver nano particle ink printed by inkjetting.


03 | Value

3D free shape electronics

FPM-Trinity can make devices of ideal shapes.

The resin substrate can be designed freely, making it easier to assemble and lighter than a conventional board. It is also possible to enclose components with resin, and even place components  above components.

Rapid manufacturing

Complete electronic devices can be manufactured in a single day.

The machine can create boards with mounted components

from scratch without stopping.

You can also create a variety of designs at the same time.

05 | Upcoming Events

プロジェクト名

Rapid+TCT

June 25 - 27, 2024

Los Angeles Convention Center
1201 S Figueroa St
Los Angeles, CA United States of America

プロジェクト名

SEMICON WEST 2024


July 9-11, 2024

Moscone Center | San Francisco, CA

06 | Specifications

Rapid manufacturing

W : 1795mm (71")

L : 1740mm (69")

H : 1480mm (58")

07 | Contact Us

FPM-Trinity is a machine being developed by FUJI CORPORATION.
It is scheduled for sale in 2025, but a pre-sale demo machine will soon be on display at Fuji America Corporation.
If you are interested in seeing the machine,
viewing samples, or learning more about the details of the machine, please complete the form to the right.
